Masuk Majalah Energia

Ini adalah kali kedua masuk majalah Energia

Monitoring Level Tangki Air dengan Sensor Pressure Berbasis ESP 8266

#include <ThingSpeak.h>

#include <ESP8266WiFi.h>

int inputpressure = A0;

//lcd

#include <Wire.h>

#include <LiquidCrystal_I2C.h>

LiquidCrystal_I2C lcd(0x27, 16, 2);

// defenisi variabel

float bacapressure;

float pressure;

float rumus;

float konstan = 0.13158;

float maxi = 935;

float zero = 175; //(kalo kekecilan hasil psi-nya, ini naikkan) paling 168

float range = 100;

// Hostpot

const char *ssid =  "ATKNet_MeetingRoom";

const char *pass =  "";

//const char *ssid =  "P_Guest";

//const char *pass =  "Phktjaya";

//const char *ssid =  "RANACITTA";

//const char *pass =  "Pandakgede999";

WiFiClient client;

//thingspeak settings

unsigned long channel = 1995294; //your channel ID number

const char *apiKey = "X1VWYOYR7WD8G3SI"; //your channel write API Key

void setup() {

  lcd.begin(); //lcd inisiasi

  pinMode(inputpressure, INPUT);

  Serial.begin(115200);

  delay(10);

  //connect to WiFi

  Serial.print("Connecting to: "); Serial.println(ssid);

  WiFi.begin(ssid, pass);



  while (WiFi.status() != WL_CONNECTED) {

    delay(500);

    Serial.print(".");

  }

  Serial.println("\nWiFi connected\n");

  ThingSpeak.begin(client); //initialize ThingSpeak

}

void loop() {

bacapressure = analogRead(inputpressure);

//rumus = ((bacapressure*5)/1024);

//rumus = ((bacapressure * 100)/1024); //dikurangin 29, karena saat nol, ada nilai 29

//rumus = ((bacapressure-175)*konstan);

rumus = ((bacapressure-zero)*(range/(maxi-zero)));

pressure = map(rumus, 0, 6.2, 0, 100 );

//pressure = map(rumus, 0, 6, 0, 100 ); //dimapping agar pressure 0-6 psi mewakili 0-100%

  Serial.print("Pressure: ");

  Serial.println(rumus);

  delay(200);

  int x = ThingSpeak.writeField(channel, 1, pressure, apiKey);

  if (x == 200) {

    Serial.println("Data " + String(pressure));

    Serial.print("pressure: "); Serial.println(pressure);

    Serial.println("Update to ThingSpeak Successful.");

  }

  else {

    Serial.println("Data " + String(pressure));

    Serial.println("Problem updating data. HTTP error code " + String(x));

  }

  Serial.println("Waiting...\n");

  lcd.setCursor(0,0);

  lcd.print("TANK LEVEL LQ");

  lcd.setCursor(0,1);

  lcd.print(pressure, 1);

  lcd.print(" %");

  //lcd.print(bacapressure);

  //lcd.print(" bit");

  delay(20000);

}

Pressure Gauge Digital Range 1450 PSIG

/*

// definisi variabel

float bacapressure;

float pressure;

float rumus;

float konstan = 0.13158;

float maxi = 935;

float zero = 175; //(kalo kekecilan hasil psi-nya, ini naikkan) paling 168

float range = 100;

rumus = ((bacapressure-zero)*(range/(maxi-zero)));

*/

//-----------------------------------------------------------

/*

//14 Mei 2023

Code by: Gede A Setiawan

gedeasetiawan@yahoo.com

KETERANGAN

LCD:

SCL: D1

SDA: D2

VCC: 5V (kalo 3v gak bisa hidup lcd nya)

GND: GND

PRESSURE SENSOR:

Red: 5v --> output byte 175 (ubah 175 di konstanta zero)

Red: 3v --> output byte 120 (ubah 120 di konstanta zero)

Black: Gnd: Ground

Yellow: data --> A0

offset: 9.48 - 11.37 = 1.89 atau setara 0.13%

*/

//-----------------------------------------------------------

float inputpressure = A0;

//lcd

#include <Wire.h>

#include <LiquidCrystal_I2C.h>

LiquidCrystal_I2C lcd(0x27, 16, 2);

// defenisi variabel

float bacapressure;

float rumus;

float konstan = 0.13158; //??

float maxi = 935; //output byte saat dikasi pressure pada range maximal

float zero = 176; //(kalo kekecilan hasil psi-nya, ini naikkan) paling 168

float range = 1450; //range maximal sensor

void setup() {

  lcd.begin(); //lcd inisiasi

  pinMode(inputpressure, INPUT);

  Serial.begin(9600);

  delay(10);

}

void loop() {

bacapressure = analogRead(inputpressure);

//rumus = (bacapressure*5/1024);

//rumus = (((bacapressure)*5/1024)-4.23);

//rumus = ((((bacapressure)/1024*5))-4.7)*1450;

rumus = ((bacapressure-zero)*(range/(maxi-zero)));

if (rumus < 0) rumus = 0;

Serial.print("Data asli: ");

Serial.print(bacapressure);

Serial.print(" Pressure: ");

Serial.println(rumus);

Serial.println("-------------");

delay(200);

  lcd.setCursor(0,0);

  lcd.print("Pressure Gauge");

  lcd.setCursor(0,1);

  lcd.print(rumus);

  lcd.print(" psig ");

  delay(200);

}

Monitoring Temperatur dan Kelembaban DHT11 via Thingspeak

//program ini berhasil connect ke thingspeak

//untuk 4 inputan/data random

#include <ESP8266WiFi.h>

#include <DHT.h>

#define WIFI_SSID "RANACITTA"

#define WIFI_PASSWORD "Pandakgede999"

#define API_KEY "N3JG5CU3O8TA9B86"

int bilanganacak;

int bilanganacak2;

#define DHTPIN D5

#define DHTTYPE DHT11

DHT dht(DHTPIN, DHTTYPE);

void setup() {

  Serial.begin(115200);

  // Connect to WiFi network

  WiFi.begin(WIFI_SSID, WIFI_PASSWORD);

  while (WiFi.status() != WL_CONNECTED) {

    delay(1000);

    Serial.println("Connecting to WiFi...");

  }

  Serial.println("Connected to WiFi");

  // Start the DHT sensor

  dht.begin();

}

void loop() {

  // Wait a few seconds between measurements

  delay(5000);

  // Read temperature and humidity from the DHT sensor

  float temperature = dht.readTemperature();

  float humidity = dht.readHumidity();

  bilanganacak = random(0,1000);

  bilanganacak2 = random(1000,5000);

  if (isnan(temperature) || isnan(humidity)) {

    Serial.println("Failed to read from DHT sensor");

    return;

  }

  // Connect to ThingSpeak server

  WiFiClient client;

  const int httpPort = 80;

  if (!client.connect("api.thingspeak.com", httpPort)) {

    Serial.println("Connection to ThingSpeak failed");

    return;

  }

  // Send data to ThingSpeak

  String url = "/update?key=" + String(API_KEY) +

               "&field1=" + String(temperature) +

               "&field2=" + String(humidity) +

               "&field3=" + String(bilanganacak) +

               "&field4=" + String(bilanganacak2);

               "&field5=" + String(0.0);

  client.print(String("GET ") + url + " HTTP/1.1\r\n" +

               "Host: api.thingspeak.com\r\n" +

               "Connection: close\r\n\r\n");

    Serial.print(" Temperature: ");

    Serial.print(temperature);

    Serial.print(" Celcius Humidity: ");

    Serial.print(humidity);

    Serial.print(" Bilangan Acak: ");

    Serial.print(bilanganacak);

    Serial.print(" Bilangan Acak 2: ");

    Serial.print(bilanganacak2);

  delay(20000);

  Serial.println(" Data sent to ThingSpeak");

}

Hotel Platform Monitoring with Arduino

//program ini sudah dimodifikasi dengan 4 data yang dikirim ke thingspeak

//saat percobaan hanya digunakan sensor pressure di A0

//field1 dan 2 pakai data dari sensor pressure

//field3 dan 4 pakai bilangan acak utk trial koneksi to thingspeak

//modified by gedeasetiawan@yahoo.com 15 Mei 2023

//

// Simple demo for feeding some random data to Pachube.

// 2011-07-08 <jc@wippler.nl>

// License: GPLv2

// Handle returning code and reset ethernet module if needed

// 2013-10-22 hneiraf@gmail.com

// Modifing so that it works on my setup for www.thingspeak.com.

// Arduino pro-mini 5V/16MHz, ETH modul on SPI with CS on pin 10.

// Also added a few changes found on various forums. Do not know what the

// res variable is for, tweaked it so it works faster for my application

// 2015-11-09 dani.lomajhenic@gmail.com

#include <EtherCard.h>

// change these settings to match your own setup

//#define FEED "000"

#define APIKEY "N3JG5CU3O8TA9B86" // put your key here

// ethernet interface mac address, must be unique on the LAN

static byte mymac[] = { 0x74,0x69,0x69,0x2D,0x30,0x31 };

const char website[] PROGMEM = "api.thingspeak.com";

byte Ethernet::buffer[700];

uint32_t timer;

Stash stash;

byte session;

//timing variable

int res = 100; // was 0

//------------------------------------pressure-----------------------

float inputpressure = A0;

//lcd

#include <Wire.h>

#include <LiquidCrystal_I2C.h>

LiquidCrystal_I2C lcd(0x27, 16, 2);

// defenisi variabel

float bacapressure;

float rumus;

float konstan = 0.13158; //??

float maxi = 935; //output byte saat dikasi pressure pada range maximal

float zero = 1; //(kalo kekecilan hasil psi-nya, ini naikkan) paling 168

float range = 15; //range maximal sensor

//-----------------------------------------------------------

void initialize_ethernet(void){

  for(;;){ // keep trying until you succeed

    //Reinitialize ethernet module

    //pinMode(5, OUTPUT);  // do notknow what this is for, i ve got something elso on pin5

    //Serial.println("Reseting Ethernet...");

    //digitalWrite(5, LOW);

    //delay(1000);

    //digitalWrite(5, HIGH);

    //delay(500);

    // Change 'SS' to your Slave Select pin, if you arn't using the default pin

    if (ether.begin(sizeof Ethernet::buffer, mymac, SS) == 0){

      Serial.println( "Failed to access Ethernet controller");

      continue;

    }

    if (!ether.dhcpSetup()){

      Serial.println("DHCP failed");

      continue;

    }

    ether.printIp("IP:  ", ether.myip);

    ether.printIp("GW:  ", ether.gwip);

    ether.printIp("DNS: ", ether.dnsip);

    if (!ether.dnsLookup(website))

      Serial.println("DNS failed");

    ether.printIp("SRV: ", ether.hisip);

    //reset init value

    res = 180;

    break;

  }

}

void setup () {

  Serial.begin(9600);

  Serial.println("\n[Hotel Platform Process Monitoring]");

  //Initialize Ethernet

  initialize_ethernet();

  lcd.begin(); //lcd inisiasi

  pinMode(inputpressure, INPUT); //untuk pressure sensor ------------------------------------------

}

void loop () {

  //if correct answer is not received then re-initialize ethernet module

  if (res > 220){

    initialize_ethernet();

//------------------------------------pressure-----------------------

bacapressure = analogRead(inputpressure);

rumus = ((bacapressure-zero)*(range/(maxi-zero))); //rumus kalkulasi pressure dlm satuan psig

//if (rumus < 0) rumus = 0;

//Serial.print("Data asli: ");

//Serial.print(bacapressure);

//Serial.print(" Pressure: ");

//Serial.println(rumus);

//Serial.println("-------------");

  lcd.setCursor(0,0);

  lcd.print("Pressure Gauge");

  lcd.setCursor(0,1);

  lcd.print(rumus);

  lcd.print(" psig ");

  delay(200);

//------------------------------------pressure-----------------------

  }

  res = res + 1;

  ether.packetLoop(ether.packetReceive());

  //200 res = 10 seconds (50ms each res)

  if (res == 200) {

    // Generate random info

    float demo = random(0,500);

    word one = random(500,1000);

    String msje;

    if (demo < 250){

      msje = "low";

    }

    else{

      msje = "high";

    }

    // generate two fake values as payload - by using a separate stash,

    // we can determine the size of the generated message ahead of time

    // field1=(Field 1 Data)&field2=(Field 2 Data)&field3=(Field 3 Data)&field4=(Field 4 Data)&field5=(Field 5 Data)&field6=(Field 6 Data)&field7=(Field 7 Data)&field8=(Field 8 Data)&lat=(Latitude in Decimal Degrees)&long=(Longitude in Decimal Degrees)&elevation=(Elevation in meters)&status=(140 Character Message)

    byte sd = stash.create();

    stash.print("field1=");

    stash.print(bacapressure);

    stash.print("&field2=");

    stash.print(rumus);

    stash.print("&field3=");

    stash.print(demo);

    stash.print("&field4=");

    stash.print(one);

    stash.save();

    //Display data to be sent

    Serial.println();

    Serial.print("Pressure Gas Lift: ");

    Serial.println(bacapressure);

    Serial.print("Pressure Gross: ");

    Serial.println(rumus);

    Serial.print("Pressure OGOL Juliet: ");

    Serial.println(demo);

    Serial.print("Pressure OGGL Juliet: ");

    Serial.println(one);

    // generate the header with payload - note that the stash size is used,

    // and that a "stash descriptor" is passed in as argument using "$H"

    Stash::prepare(PSTR("POST /update HTTP/1.0" "\r\n"

      "Host: $F" "\r\n"

      "Connection: close" "\r\n"

      "X-THINGSPEAKAPIKEY: $F" "\r\n"

      "Content-Type: application/x-www-form-urlencoded" "\r\n"

      "Content-Length: $D" "\r\n"

      "\r\n"

      "$H"),

    website, PSTR(APIKEY), stash.size(), sd);

    // send the packet - this also releases all stash buffers once done

    session = ether.tcpSend();

 // added from: http://jeelabs.net/boards/7/topics/2241

 int freeCount = stash.freeCount();

    if (freeCount <= 3) {   Stash::initMap(56); }

  }

   const char* reply = ether.tcpReply(session);

   if (reply != 0) {

     res = 0;

     Serial.println(F(" >>>REPLY recieved...."));

 //    Serial.println(reply);

   }

   delay(300);

}

LEBARAN, ACTING, PLC BRAVO

On 19 April - 3 Mei 2023

Setelah off kemaren hanya seminggu, on kali ini 15 hari untuk back up teman2 cuti lebaran. Seminggu pertama aku masih sendiri dan acting 4 hari setelah mas Sigit off hari Senin sore. Selama on duty hampir tiap sore menyempatkan olahraga sekitar 1/2 jam di Attaka. Jalan cepat di topdeck, sepeda statis atau ngegym di bawah. Pokoknya harus ada perubahan gaya agar kolesterol LDL turun. On kali ini juga melepas mas Mahe dan Pak Yamani memasuki pensiun.

19 otw to santan via propane

20 ganti pilot water regulator, ganti Temp transmitter 8014 karna error, over range

21 di lq aja, repair water regulator prod n pilot

22 lebaran, mas sigit beli makanan 1 4jt. Sholat di bawah helidec. Saya dan mas Mahe dokumentasi. Ganz nyiapin kursi di samping crane tp gak jadi karena hujan deres. Nonton film dono

23 lebaran, repair water regulator ex production

24 di LQ aja, prepare positioner LCV melahin

25 acting1, acara perpisahan mas mahe purnakarya

26 acting2, meeting with pak wawan

27 acting3, KC1 mati dan BDV tdk bisa closed. Closed out meeting.

28 acting4, meeting pak wawan. ngurus vaksin VGR, trakindo yang datang 3 lagi.

29 project plc bravo, install tubing dan kabel utk PT

30 bravo plc, install kabel shipping pump

1 ke foxtrot telemetri gross to PI. Ditemukan parallel gas meter ke oscar. Dilepas mau connect.

2 teman2 vaksin VGR ke santan. Edit PI HMI di production. Sama Kadri n yudith

3 repair auto drain P dan CP

4 off naik citilink via sby with lukman naik mobil ke apt pranoto. 400rb. Jam 8.30 sampe di bandara

Trip ON:

07.00-09.30 bpn-robinson

10.10-13.00 robinson-santan

14.00-15.45 santan-attaka

Trip OFF:

atk-stn 5.30-7.00 peacock+KCL

stn-pranoto 7.15-8.50 (bis)

stn-pranoto 7.10-8.30 (mobil)

pranoto-robinson 8.50-9.30

robinson-sepinggan 10.00-12.15
